ESBE T4 Pump Control Set

Underfloor heating with thermostatic mixing valve

Let’s talk, call us on 01489 779068

Valve Icon
OEM Icon
ESBE Icon
Energy Icon
OEM Icon

The ESBE compact T4 thermostatic 4-port pump set is suitable for applications with a max output of 18kW.

Features

  • 20°C-55°C temperature range for force screed drying (BS1264)

  • ‘A’ rated pump (Grundfos or Wilo)

  •  Integrated check valves for easy filling

  •  Temperature gauge

  •  Assembled in the UK: pre-tested, packaged and ready for instant installation

  • Fully reversible (Left or Right sided manifold)

  • Available in 200mm, 210mm and 225mm manifold connection centres

  • Side or bottom entry connections

  • 2 Year warranty

Specification

  • Kv: 3.4Kv (Up to 220sqm / 18kW)

  • Temperature range: 20°C – 55°C

  • Max temperature range:

    Continuously = 95°C / Temporarily = 100°C

  • Maximum supply pressure: 10 Bar

Connections

Primary connections – 3/4” BSPF
Manifold connections – 1” BSPM

Optional extras

Primary isolation valves
Safety temperature switch
Manifold isolation valves
Compression fittings





OEM Icon

Downloads

PDF Product Download OEM

Brochure

Overview of the Essco Underfloor Heating Pump Pack range. Click to download.

PDF Product Download OEM

ESBE T4 Wilo Data Sheet

Technical data sheet for the ESBE T4 Wilo pump pack. Click to download.

PDF Product Download OEM

ESBE T4 Grundfos Data Sheet

Technical data sheet for the ESBE T4 Grundfos pump pack. Click to download.

PDF Product Download OEM

ESBE T4 Wilo Installation Instructions

Installation Instructions for the ESBE T4 Wilo Pump Pack. Click to download.

PDF Product Download OEM

ESBE T4 Grundfos Installation Instructions

Installation Instructions for the ESBE T4 Grundfos Pump Pack. Click to download.
